Lancer Sensation Collection
Sensation 30" Compact
Dimensions
Height: 37.25”
Width: 30”
Depth: 31”
Electrical
115V/60Hz, 6 Amps
Weight
With Ice: 525 lbs
Shipping: 335 lbs
Ice
Capacity: 250 lbs
Dispensable: 185 lbs
Fittings
Carbonated Water Inlet: 3/8”
Plain Water inlet: 3/8”
Syrup inlets: 1/4”
Sensation 44" Model
Dimensions
Height: 39””
Width: 44”
Depth: 31”
Electrical
115V/60Hz, 6 Amps
Weight
Empty: 146 lbs
Operating: 193 lbs
Shipping: 160 lbs
Ice
Capacity: 312 lbs
Dispensable: 255 lbs
Fittings
Carbonated Water Inlet: 3/8”
Plain Water inlet: 3/8”
Syrup inlets: 1/4”
Twin Pour Dispenser
Dimensions
Height: 39.375” (1000.1 mm)
Width: 44” (1117.6 mm)
Depth: 31” (787.4 mm)
Electrical
115V/60Hz, 6 Amps
220-240V, 50/60 Hz, 3 Amps
Weight
With Ice: 745 lbs (337.9 kg)
Shipping: 585 lbs (265 kg)
Ice
Capacity: 312 lbs (142 kg)
Dispensable: 255 lbs (116 kg)
Accepts 30” and 22” and 44” wide ice makers
(adapters may be required)
Flex Manifold Configuration
Total carb / non carb flexibility
Up to 24 brands
(10 chilled / 2 ambient per nozzle)
Up to 8 bonus Flavors (4 per nozzle)
Lancer Flavor Select
Flavor Select 22" Model
Dimensions
Height: 40.25”
Width: 22”
Depth: 30.5”
Electrical
115V / 60Hz, 7Amps
Weight
Without Ice: 280 lbs
With Ice: 480 lbs
Shipping: 310 lbs
(141 kg)
Ice
Capacity: 200 lbs
Dispensable: 170 lbs
Fittings
Syrup inlets: 3/8”
Soda inlets: 3/8”
Water
Filtered water 50 psi min
(Water booster recommended)
Flavor Select 30" Model
Dimensions
Height: 40.25”
Width: 30”
Depth: 30.5”
Electrical
115V / 60Hz, 7Amps
Weight
Without Ice: 320 lbs
With Ice: 610 lbs
Shipping: 356 lbs
Ice
Capacity: 280 lbs
Dispensable: 215 lbs
Fittings
Syrup inlets: 3/8”
Soda inlets: 3/8”
Water
Filtered water 50 psi min
(Water booster recommended)
Flavor Select 44"
Dimensions
Height: 40.25”
Width: 44.875”
Depth: 30.5”
Electrical
115V / 60Hz, 7Amps (2x)
Weight
Without Ice: 620 lbs
With Ice: 1020 lbs
Shipping: 710 lbs
Ice
Capacity: 400 lbs
Dispensable: 340 lbs
2 Independent Ice Bins
Fittings
Syrup inlets:
Soda inlets:
Water
Filtered water 50 psi min
(Water booster recommended)
Lancer Legacy Series
Legacy Series 22"
Dimensions
Height: 35.375”
Width: 22”
Depth: 30.5”
Space Required
24” W x 31.5” D
Electrical
115V/60Hz, 3Amps
230V/50Hz, 1.5Amps
Weight
With ice: 405 lbs
Shipping: 255 lbs
Ice
Capacity: 180 lbs
Dispensable: 150 lbs
Fittings
Soda Inlets: 3/8”
Syrup Inlets: 3/8”
Legacy Series 30"
Dimensions
Height: 35.375”
Width: 30”
Depth: 30.5”
(775 mm)
Space Required
32” W x 31.5” D
Electrical
115V/60Hz – 230/50Hz
Weight
With ice: 525 lbs
Shipping: 305 lbs
Ice
Capacity: 250 lbs
Dispensable: 175 lbs
Fittings
Soda Inlets: 3/8”
Syrup Inlets: 3/8”
Legacy Series 44"
Dimensions
Height: 35.375”
Width: 44”
Depth: 30.5”
Space Required
46” W x 31.5” D
Electrical
115V/60Hz – 230/50Hz
Weight
With ice: 760 lbs
Shipping: 460 lbs
Ice
Capacity: 360 lbs
Dispensable: 300 lbs
Fittings
Soda Inlets: 3/8”
Syrup Inlets: 3/8”
